Fire Alarm Controller Fire Linkage Controller

Professional Fire Alarm Controller Fire Linkage Controller manufacturer - Baian. We offers reliable, certified fire fighting equipment backed by technical support and global experience.

ISO 9001 Global shipping Pyrosafe Tech
  • Engineering support with NFPA / EN compliant documentation
  • Worldwide shipping with stock-ready warehouse capacity
  • Certified equipment with traceable quality control
Specifications

Technical parameters

ParameterValue
<span style="font-weight: bold;color: #fff;background-color: #073980">Wiring system</span><span style="font-weight: normal">Non-polar dual-wire battery</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">AC input voltage</span><span style="background-color: #dad6d5">220V1015, 50Hz±1%</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">AC input power</span>≤300W
<span style="font-weight: bold;color: #fff;background-color: #073980">DC backup power</span><span style="background-color: #dad6d5">DC24V/24Ah fully sealed maintenance-free battery</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">Circuit capacity</span>≤242 address points; Total capacity: ≤5808 address points (24 circuits)
<span style="font-weight: bold;color: #fff;background-color: #073980">Number of multi-line linkage control monitors</span><span style="background-color: #dad6d5">≤10 (12 buttons/pan) E18000G; ≤6 (12 buttons/pan) E18000T</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">Number of bus linkage control monitors</span>≤20 (60 buttons/pan) E18000G; ≤10 ( 60 buttons/panel) E18000T
<span style="font-weight: bold;color: #fff;background-color: #073980">Bus length</span><span style="background-color: #dad6d5">≤2000 meters (cross-sectional area ≥1.5mm²)</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">Dimensions</span><span style="background-color: #fff">Length 570mm × Width 495mm × Height 1781mm (E18000G)</span><br> <span style="background-color: #fff">Length 1102mm × Width 1123mm × Height 1269mm (E18000T)</span>
<span style="font-weight: bold;color: #fff;background-color: #073980">Standards implemented</span><span style="background-color: #dad6d5">GB4717-2005 "Fire Alarm Controllers"</span><br> <span style="background-color: #dad6d5">GB16806-2006 "Fire Protection Linkage Control Systems"</span>
Product Details

About this product

Professional Fire Alarm Controller Fire Linkage Controller manufacturer - Baian. We offers reliable, certified fire fighting equipment backed by technical support and global experience.
